Scope of work executed by our company:

1. Seeking of an original model of transformer which will satisfy to requirements indicating in the specification;
2. Carrying out of calculations of the model;
3. Developments of drawings of basic parts of transformer;
4. Design review of the project by videoconferencing;
5. Development of detail manufacturing drawings of transformer;
6. Support during transformer manufacturing (20 man days).

List of manufacturing drawings, that were reviewed:

1. Core
2. Insulation
3. Windings
4. Active part
5. Leads
6. Common view
7. Tank
8. Cooling system.

List of calculations:

1. Calculation of I2R, circulating and eddy losses in winding;
2. Calculation of impulse stresses and safety margins between all disks of all windings;
3. Turn insulation calculation;
4. Major insulation calculation: calculation of safety margins between winding and grounding parts of a transformer, between leads and grounding parts of a transformer or, between bushing and grounding parts of a transformer.

You can see full list of calculations on the project page, link below
